Kartar 4536 2 Wheel Drive Tractor

Kartar 4536 and Kartar 4536 4WD are strong and reliable tractors, suitable for regular farming work. Both models come with a Kirloskar 3R1040 engine, which is a 3-cylinder, water-cooled, DI type engine. The bore/stroke is 105 / 120 mm and the displacement is 3120 cc. It delivers smooth and stable performance at 2000 RPM. The dry type air cleaner helps protect the engine from dust.

Both tractors are equipped with a partial constant mesh gearbox with 8 forward and 2 reverse gears, making operation simple and effective. The final drive is in-board reduction type, ensuring proper power delivery to the wheels. Oil immersed brakes (OIB) provide strong and reliable braking.

The PTO comes with 540, 6-spline MR-PTO, suitable for running different implements. The forward speed ranges from 2.05 to 30.41 km/h, while reverse speed is from 2.63 to 10.53 km/h.

It has a 280 mm dry type dual clutch for smooth functioning. The ADDC hydraulic system offers a lifting capacity of 1800 kgf, making it capable of handling various implements.

The weight is 2380 kg for the 2WD model and 2710 kg for the 4WD model, giving good balance and grip. It also comes with an optional fibre canopy with a rear view mirror. A heavy-duty front bumper is provided for extra protection.

Reverse PTO is optional in the 2WD model and standard in the 4WD model. It has a double-acting DC valve and an 88 Ah, 12V battery.

Tyre sizes for the 2WD model are 6.5×16 / 6.0×16 (front) and 14.9×28 / 13.6×28 (rear). For the 4WD model, front tyres are 9.5×18 / 8.0×18, while rear tyres remain the same.

In terms of lighting, the 2WD model has bulb-type fender tail lamps, while the 4WD model gets LED tail lamps. Both tractors come with balanced power steering for easy handling. Footboard and heat guard are also provided for operator comfort.

Overall, Kartar 4536 and 4536 4WD are practical and efficient tractors, ideal for normal and medium-level farming work.
